IDEC SmartRelay functions
132 IDEC SmartRelay Manual
Parameter T
Note the defaults for parameter T in Chapter 4.3.2.
The time for parameter T can also be preset based on the
actual va
lue of another, already-configured function. You
can use the actual values of the following functions:
• Analog comparator (actual value Ax - Ay, see Chapter
4.4.18)
• Analog trigger (actual value Ax, see Chapter 4.4.16)
• Analog amplifier (actual value Ax, see Chapter 4.4.20)
• Analog multiplexer (actual value AQ,
see Chapter 4.4.
26)
• Analog ramp control (actual value AQ, see Chapter
4.4.27)
• Analog math (actual value AQ, see Chapter 4.4.30)
• PI controller (actual value AQ,
see Chapter 4.4.28)
• Counter (actual value Cnt, see Chapter 4.4.13)
Select the required function by the block number. The
time
base is adju
stable. Please note the following listing:
Valid ranges of the timebase, if T = parameter
The display in programming mode (example):
Valid ranges of the timebase, if T = Actual value of an already-
programmed function
Timebase max. value min. resolution Accuracy
s (seconds) 99:99 10 ms +
10 ms
m (minutes) 99:59 1s +
1 s
h (hours) 99:59 1 min + 1 min
Timebase max. value Meaning Accuracy
ms 99990 Number of ms + 10 ms
s 5999 Number of s +
1 s
m 5999 Number of min +
1 min
