IDEC SmartRelay functions
IDEC SmartRelay Manual 133
The display in programming mode (example):
B12 +R
T
B006 m
If the referenced block (B6, in the example) returns a value
that lies out of the valid range, the value is rounded up or
down to the next valid value.
Parameter preset = Actual value of an already-programmed function
How to include the actual value of an already-programmed
function:
1. Press
to move the cursor to the equal sign of
parameter T.
2. Press to change the equal sign into an arrow. If it
exists, the last referenced block and its timebase is
shown.
B12 +R
T B006s
3. Press to move the cursor to the ”B” of the shown block,
and then press
to select the required block number.
4. Press
to move the cursor to the block’s timebase and
press
to select the required timebase.
B12 +R
T
B006 m
