IDEC SmartRelay functions
152 IDEC SmartRelay Manual
Parameter assignment screen form
View of the parameter assignment screen form, for example
for Cam1 and the Pulse setting:
B1 1+
D=MTWTFSS
On =06:30
Off=08:00
B1 4+
Pulse=Off
Block B1
Cam 1
See Showing/hiding parameters -
Parameter protection mode on
page 90
Weekdays (daily)
On-time (06.30 h)
Off-time (08:00 h)
Pulse form
Pulse setting: On or Off
Days of the week
The suffix of ”D=” (Day) has the following meaning:
• M : Monday
• T : Tuesday
• W : Wednesday
• T : Thursday
•F:Friday
• S : Saturday
• S : Sunday
Uppercase letters indicate a specific day of the week. A “-”
in
dicates no selection fo
r the day of the week.
On-/Off-times
Any time between 00:00 h and 23:59 h is possible.You can
also co
nfigure the on time to be a pulse signal. The timer
block will be activated at the specified time for one cycle and
then the output is reset.
- -:- - means: No on-/off-times set.
