IDEC SmartRelay functions
198 IDEC SmartRelay Manual
Example
This is how two message texts could be shown:
Display field of IDEC SmartRelay in RUN mode
Key
Press
Example: Message text with priority 30
Example: Message text with priority 10
Date and current time-of-day
(only for versions with real-time clock).
Message Ticking
You can configure message text lines to tick or not tick. Two
types of message ticking ex
ist:
• Character by character
• Line by line
Messages that tick character by character scroll off the
character
s of the message line one character at a time to the
left with the additional characters scrolling in one at a time
from the right. The time interval for the tick is specified by the
TickTime message text setting.
Messages that tick line by line by line scroll one half of the
me
ssage of
f the display to the left with the second half of the
message scrolling in from the right. The time interval for the
tick is ten times the TickTime parameter. The two halves of
the message simply alternate on the IDEC SmartRelay
Display or Text Display.
