IDEC SmartRelay installation and wiring

42 IDEC SmartRelay Manual

FL1E-H12RCE / FL1E-B12RCE / FL1E-H12SND

FL1B-M08B2R2/FL1B-M08B1S2

FL1E-H12RCE / FL1E-B12RCE / FL1E-H12SND

I1~I8

3.6kΩ 270kΩ

2.21kΩ47nF

Internal Circuit

Digital DC Input

I1~I8

3.6kΩ

2.2kΩ100nF

Internal Circuit

270kΩ

Digital DC Input

I1, I2, I7, I8

54kΩ

+5V

18kΩ

10nF

Internal Circuit

Analog Input (0-10V)

U1, U2

M1, M2

38kΩ

+5V

38kΩ

10nF

Internal Circuit

FL1B-J2B2 

Analog Input (0-10V)
