IDEC SmartRelay installation and wiring

IDEC SmartRelay Manual 45

Requirements for transistor outputs

The load connected to IDEC SmartRelay must have the

following characteristics:

• The maximum switched current is 0.3 A per output.

Connecting

This is how you connect the load to an IDEC SmartRelay

with transistor ou

tputs:

FL1B-M08

Q5 Q6MM

Load: 24 V DC, 0.3 A max.

Load Load
