IDEC SmartRelay functions
136
IDEC SmartRelay Manual
Functional description
A 0 to 1 signal transition at input Trg sets output Q. The next
1 to 0 transition at Trg retriggers the current time T
a
, and out-
put Q remains set.
Output Q is reset when T
a
= T. You can output a warning sig-
nal before the off-delay time (T - T
!
) has expired to reset Q
for the time of the pre-warning period T
!L
.
A further one-shot at input Trg during T
a
retriggers the time
T
a
.
If retentivity is not set, output Q and the expired time are re-
set after a power failure.
Preset of the Par parameter
Note the defaults specified in Chapter 4.3.2.
Note
All times must have the same timebase.
View in programming mode (example):
Press
B9 1+R
T
=60:00s
Protection mode and retentivity
Off-delay time
B9 2
T! =05:00s
T!L
=00:10s
Start of the off-warning period
(T - T
!
)
Off-warning time
