IDEC SmartRelay installation and wiring
24
IDEC SmartRelay Manual
2.3.2 Connecting IDEC SmartRelay inputs
Requirements
At the inputs you connect sensor elements such as: momen-
tary switches, switches, light barriers, daylight control
switches etc.
Sensor characteristics for IDEC SmartRelay
Note
The digital inputs of FL1C-H12RCC/FL1C-B12RCC are divided
into two groups, each consisting of four inputs. Within the same
group, all inputs must be operated on the same phase. Different
phases are only possible between the groups.
Example:
I1 to I4 on phase L1, I5 to I8 on phase L2.
Inputs within the FL1B-M08C2R2 may not be connected to differ-
ent phases.
FL1C-H12RCE
FL1C-B12RCE
FL1B-M08B2R2
FL1C-H12SND
FL1B-M08B1S2
I1 ... I6 I7, I8 I1 ... I6 I7, I8
Signal status 0 < 5 VDC < 5 VDC < 5 VDC < 5 VDC
Input current < 1.0 mA < 0.05 mA < 1.0 mA < 0.05 mA
Signal status 1 > 8 V DC > 8 V DC > 8 V DC > 8 V DC
Input current > 1.5 mA > 0.1 mA > 1.5 mA > 0.1 mA
FL1C-
H12RCA/
FL1C-
B12RCA (AC)
FL1B-M08
D2R2 (AC)
FL1C-
H12RCA/
FL1C-
B12RCA (DC)
FL1B-M08
D2R2 (DC)
FL1C-
H12RCC/
FL1C-
B12RCC (AC)
FL1B-M08
C2R2 (AC)
FL1C-
H12RCC/
FL1C-
B12RCC (DC)
FL1B-M08
C2R2 (DC)
Signal status 0 < 5 V AC < 5 V DC < 40 V AC < 30 V DC
Input current < 1.0 mA < 1.0 mA < 0.03 mA < 0.03 mA
Signal status 1 > 12 V AC > 12 V DC > 79 V AC > 79 V DC
Input current > 2.5 mA > 2.5 mA > 0.08 mA > 0.08 mA
