Technical data
IDEC SmartRelay Manual 267
A.5 Technical data: FL1C-...12RCE and FL1B-
M08B2R2
FL1C-H12RCE
FL1C-B12RCE
FL1B-M08B2R2
Power supply
Input voltage 12/24 V DC 12/24 V DC
Permissible range 10.8 ... 28.8 V DC 10.8 ... 28.8 V DC
Reverse polarity protection Yes Yes
Power consumption
• 12 V DC
• 24 V DC
30 ... 140 mA
20 ... 75 mA
30 ... 140 mA
20 ... 75 mA
Voltage failure buffering
• 12 V DC
• 24 V DC
typ. 2 ms
typ. 5 ms
typ. 2 ms
typ. 5 ms
Power loss
• 12 V DC
• 24 V DC
0.3 ... 1.7 W
0.4 ... 1.8 W
0.3 ... 1.7 W
0.4 ... 1.8 W
Backup of the real–time clock
at 25 ˚C
typ. 80 h
Accuracy of the real–time
clock
typ. ±2 s / day
Electrical isolation No No
Digital inputs
Number 8 4
Electrical isolation No No
Input voltage L+
• Signal 0
• Signal 1
< 5 V DC
> 8 V DC
< 5 V DC
> 8 V DC
Input current at
• Signal 0
• Signal 1
< 1.0 mA (I1...I6)
< 0.05 mA (I7, I8)
> 1.5 mA (I1... I6)
> 0.1 mA (I7, I8)
< 1.0 mA
> 1.5 mA
