Programming IDEC SmartRelay
78
IDEC SmartRelay Manual
6. To move the cursor to the input of Q1, i.e. to B2, press :
7. Confirm with OK.
8. Now set the connector ‘x’ at output Q1 instead of block
B2. To do so:
- Select the Co list: Press ▲ or ▼
- Accept the Co list: Press OK
- Select ‘x’: Press ▲ or ▼
- Apply ‘x’: Press OK
Result: Block B2 is deleted, because it is no longer used in
the circuit. This includes all blocks connected to B2. In this
example, block B1 also.
3.6.10 Correcting typing errors
Programming errors can be corrected easily in IDEC Smart-
Relay :
• Provided editing mode is not yet closed, you can revert by
one step by pressing ESC.
• If you have already configured all inputs, simply reconfig-
ure the faulty input:
1. Move the cursor to the faulty position
2. Change to editing mode. Press OK
3. Enter the correct input circuit.
You can only replace a block with a block that has exactly the
same number of inputs. However, you can delete the old
block and then insert a new one. You can choose any new
block.
▲
B2 Q1
