IDEC SmartRelay Series User Manual

256 IDEC SmartRelay Manual
A Technical data
A.1 General technical data
Criterion Tested in accordance
with
Values
IDEC SmartRelay
Basic:
Dimensions (WxHxD)
Weight
Installation
72 x 90 x 55 mm
Approx. 190 g
on a 35 mm profile rail
4 module widths
or wall mounting
IDEC SmartRelay
expansion module:
Dimensions (WxHxD)
Weight
Installation
36 x 90 x 55 mm
Approx. 90 g
on a 35 mm profile rail
4 module widths
or wall mounting
Climatic conditions
Ambient temperature
Horizontal installation
Vertical installation
Low temperature to IEC
60068-2-1
High temperature to
IEC 60068-2-2
0 ... 55 °C
0 ... 55 °C
Storage/shipping -40 °C... +70 °C
Relative humidity IEC 60068-2-30 From 10 to 95 %
no condensation
Air pressure 795 ... 1080 hPa
Pollutants IEC 60068-2-42
IEC 60068-2-43
SO
2
10 cm
3
/m
3
,
4 days
H
2
S 1 cm
3
/m
3
,
4 days
