Technical data
IDEC SmartRelay Manual 257
Ambient mechanical conditions
Protection mode IP20
Vibrations: IEC 60068-2-6 5 ... 9 Hz (constant
amplitude 3.5 mm)
9 ... 150 Hz (constant
acceleration 1 g)
Shock IEC 60068-2-27 18 shocks
(half-sine wave 15g/
11 ms)
Drop IEC 60068-2-31 Drop height 50 mm
Free fall (packaged) IEC 60068-2-32 1 m
Electromagnetic compatibility (EMC)
Noise emission EN 55011/A
EN 55022/B
EN 50081-1
(domestic area)
Limit class B group 1
Electrostatic discharge IEC 61000-4-2
Severity 3
8 kV air discharge
6 kV contact discharge
Electromagnetic fields IEC 61000-4-3 Field strength 10 V/m
HF currents on cables
and cable shielding
IEC 61000-4-6 10 V
Burst pulses IEC 61000-4-4 Severity 3 2 kV (supply and sig-
nal lines)
High-energy surge
pulse (applies only to
FL1C-H12RCC)
IEC 61000-4-5 Severity 3 1 kV (power lines)
symmetrical
2 kV (power lines)
asymmetrical
Safety to IEC / VDE
Clearance and creep-
age distance rating
IEC 60664, IEC 61131-2,
EN 50178
cULus to UL 508, CSA
C22.2 No. 142
With FL1C-B12RCC/
FL1C-H12RCC, also
VDE 0631
Fulfilled
Insulation strength IEC 61131-2 Fulfilled
Criterion Tested in accordance
with
Values
2 kV (supply)
1 kV (signal lines)
