IDEC SmartRelay Series - Selecting the Parameters

Configuring IDEC SmartRelay
200
IDEC SmartRelay Manual
5.1.2 Selecting the parameters
To select a parameter:
1. On the parameter assignment menu, select
‘Set Param’: Press ▼ or ▲
2. Confirm with OK.
IDEC SmartRelay shows the first parameter. If no pa-
rameter can be set, you can press ESC to return to the
parameter assignment menu.
3. Now, select the desired parameter:Press ▲ or ▼.
4. Select the parameter you want to edit, and press OK.
Stop
>Set Param
Set Clock
Prg Name
B9 1
Press ESC
No Param
T =60:00s
Ta =06:00s
Block number
Display number for functions with
several displays
The value set at
parameter T (Time)
The current time in the IDEC
SmartRelay
No parameters for editing:
Press ESC to return to the
parameter assignment menu
