IDEC SmartRelay Series User Manual

Programming IDEC SmartRelay
52
IDEC SmartRelay Manual
3.5 Overview of the IDEC SmartRelay menus
Programming mode
Parameter assignment mode
For more details on these menus, refer to Appendix D.
>Program..
Card..
Clock..
Start
>Edit..
Clear Prg
Password
> Card
Card
CopyProtect
OK
OK
ESC
ESC
= IDEC
SmartRelay
>Set Clock
S/W Time
Sync
ESC
OK
Main menu Programming menu
Transfer menu
Real-time clock menu
Parameter assignment menu
>Stop
Set Param
Set Clock
Prg Name
