IDEC SmartRelay Series User Manual

Programming IDEC SmartRelay
68
IDEC SmartRelay Manual
3.6.6 Switching IDEC SmartRelay to RUN mode
In the main menu, select RUN to start IDEC SmartRelay.
1. To return to the main menu: Press ESC
2. Move the '>' cursor to 'Start': Press ▲ or ▼
3. To confirm 'Start': Press OK
IDEC SmartRelay runs the circuit program and and shows
the following display:
2003-01-27
Mo 09:00
I:
0.. 123456789
1..0123456789
2..01234
Q:
0.. 123456789
1..0123456
M:
0.. 123456789
1..0123456789
2..01234
ESC+Key
Display field of the IDEC SmartRelay in RUN mode
Date and current time-of-day (only
for versions with realtime clock).
This element flashes if the date and
time are not set.
Inputs I1 to I9
Inputs I10 to I19
Inputs I20 to I24
Outputs Q1 to Q9
Outputs Q10 to Q16
Markers M1 to M9
Markers M10 to M19
Markers M20 to M24
4 cursor keys for manual intervention
in the circuit program (ESC+key)
Press
Press
Press
Press
Courtesy of Steven Engineering, Inc. ● 230 Ryan Way, South San Francisco, CA 94080-6370 ● General Inquiries: (800) 670-4183 ● www.stevenengineering.com
