2.4 Switching on the IDEC SmartRelay /
Power On
IDEC SmartRelay does not have a power switch. The reac-
tion of IDEC SmartRelay during startup depends on
• Whether a circuit program is stored in IDEC SmartRelay
• Whether a memory cartridge (card) is inserted
• Whether this is a IDEC SmartRelay version without dis-
play unit (FL1C-B12...)
• The status of IDEC SmartRelay at the time of power fail-
ure.
All possible reaction of IDEC SmartRelay are described on
the following page.
Note
After power-up, the FL1C performs initialization. After completing
initialization, the FL1C is ready to start to run. During initialization,
a sandglass is displayed on the CPU module with display, or the
LED is lit red on the CPU module without display.
Initialization time (regardless of expansion module)
When a memory cartridge is installed: Max. 10 sec
When a memory cartridge is not installed: Max. 9 sec
