Programming IDEC SmartRelay
IDEC SmartRelay Manual 53
3.6 Writing and starting the circuit program
After you have designed a circuit, you want to write it to your
IDEC SmartRelay. The small example below shows how to
do this.
3.6.1 Select programming mode
You have connected the IDEC SmartRelay to the power sup-
ply and switched it on. The display now shows you the mes-
sage:
Switch the IDEC SmartRelay to programming mode by
pressing the ESC. This will take you to the main menu of the
IDEC SmartRelay:
The first character in the first line is the ">" cursor. Press ▲
and ▼ to move the ">" cursor up and down. Move it to "Pro-
gram.." and confirm with OK. IDEC SmartRelay opens the
programming menu.
>Program..
Card..
Clock..
Start
IDEC SmartRelay’s main menu
>Edit..
Clear Prg
Password
IDEC SmartRelay’s programming menu
