Programming IDEC SmartRelay
54
IDEC SmartRelay Manual
Here you can also move the ">" cursor by pressing ▲ and ▼.
Move the ">" cursor to "Edit.." (for editing, i.e. input) and con-
firm with OK.
Move the ">" cursor to "Edit Prg" (for editing the circuit pro-
gram) and confirm with OK. IDEC SmartRelay now shows
you the first output:
You are now in programming mode. Press ▲ and ▼ to select
the other outputs. Now start to edit your circuit program.
Note
Because we have not yet saved a password for the circuit program
in IDEC SmartRelay, you can directly enter editing mode. When
you select “Edit Prg” after you have saved a password-protected
circuit program, you are prompted to enter a password and to con-
firm it with OK. You can only edit the program after you have en-
tered the correct password (see Chapter 3.6.5.).
>Edit Prg
Edit Name
Memory?
The Edit menu of IDEC SmartRelay
Q1
The first output of IDEC SmartRelay
