IDEC SmartRelay Series User Manual

Technical data
264
IDEC SmartRelay Manual
A.4 Technical data: FL1C-...12RCA and FL1B-
M08D2R2
FL1C-H12RCA
FL1C-B12RCA
FL1B-M08D2R2
Power supply
Input voltage 24 V AC/DC 24 V AC/DC
Permissible range 20.4 ... 26.4 V AC
20.4 ... 28.8 V DC
20.4 ... 26.4 V AC
20.4 ... 28.8 V DC
Reverse polarity protection
Permissible mains frequency 47 ... 63 Hz 47 ... 63 Hz
Power consumption
• 24 V AC
• 24 V DC
40 ... 100 mA
20 ... 75 mA
40 ... 100 mA
20 ... 75 mA
Voltage failure buffering typ. 5 ms typ. 5 ms
Power loss
• 24 V AC
• 24 V DC
0.9 ... 2.7 W
0.4 ... 1.8 W
0.9 ... 2.7 W
0.4 ... 1.8 W
Backup of the real–time clock
at 25˚C
typ. 80 h typ. 80 h
Accuracy of the real–time clock typ. ±2 s / day
Digital inputs
Number 8,
optional P action or N
action
4,
optional P action or N
action
Electrical isolation No No
Input voltage
• Signal 0
• Signal 1
L
< 5 V AC/DC
> 12 V AC/DC
L
< 5 V AC/DC
> 12 V AC/DC
