Technical data
IDEC SmartRelay Manual 265
Input current at
Signal 0
Signal 1
< 1.0 mA
> 2.5 mA
< 1.0 mA
> 2.5 mA
Delay time at
•0 to 1
•1 to 0
typ. 1.5 ms
typ. 15 ms
typ. 1.5 ms
typ. 15 ms
Line length (unshielded) 100 m 100 m
Analog inputs
Number
Range
max. Input voltage
Digital outputs
Number 4 4
Output type Relay outputs Relay outputs
Electrical isolation Yes Yes
In groups of 1 1
Control of a digital input Yes Yes
Output voltage
Output current
Continuous current I
th
max. 10 A per relay max. 5 A per relay
Incandescent lamp load
(25000 switching cycles) at
1000 W 1000 W
Fluorescent tubes with ballast
(25000 switching cycles)
10 x 58 W 10 x 58 W
FL1C-H12RCA
FL1C-B12RCA
FL1B-M08D2R2
