IDEC SmartRelay Series User Manual

Technical data
266
IDEC SmartRelay Manual
Fluorescent tubes, convention-
ally compensated
(25000 switching cycles)
1 x 58 W 1 x 58 W
Fluorescent tubes, uncompen-
sated (25000 switching cycles)
10 x 58 W 10 x 58 W
Short circuit–proof and
overload–proof
Short–circuit current limitation
Derating none; across the en-
tire temperature
range
none; across the en-
tire temperature
range
Short circuit–proof cos 1 Power protection
B16,
600A
Power protection
B16,
600A
Short–circuit proof cos 0.5 to
0.7
Power protection
B16,
900A
Power protection
B16,
900A
Parallel output circuits
for power increase
Not permitted Not permitted
Protection of output relay
(if desired)
max. 16 A,
characteristic B16
max. 16 A,
characteristic B16
Switching rate
Mechanical 10 Hz 10 Hz
Electrical
Ohmic load/lamp load 2 Hz 2 Hz
Inductive load 0.5 Hz 0.5 Hz
FL1C-H12RCA
FL1C-B12RCA
FL1B-M08D2R2
