IDEC SmartRelay installation and wiring
IDEC SmartRelay Manual 13
2.1 Setup of the modular IDEC SmartRelay
2.1.1 Maximum setup
Maximum setup of a IDEC SmartRelay with analog inputs
(FL1C-H12RCE/FL1C-B12RCE and FL1C-H12SND)
IDEC SmartRelay Basic, 4 digital modules and 3 analog modules
Note
When using inputs I7 / AI1 and I8 / AI2 as analog inputs, AI1 and
AI2, do not use them as digital inputs I7/I8.
Maximum setup of a IDEC SmartRelay without analog inputs
(FL1C-H12RCA/FL1C-B12RCA and FL1C-H12RCC/FL1C-
B12RCC)
IDEC SmartRelay Basic, 4 digital modules and 4 analog modules
High-speed/optimal communication performance
For optimal and high-speed communication performance
between IDEC SmartRelay Basic and the various modules,
we recommend you install the “digital modules first, then the
analog modules” (example above).
I1......I6, I7, I8
AI1, AI2
IDEC Smart-
Relay Basic
Q1...Q4
I9...I12
FL1B-
M08
Q5...Q8
I13...I16
FL1B-
M08
Q9...Q12
I17...I20
FL1B-
M08
Q13...Q16
I21...I24
FL1B-
M08
AI3, AI4
FL1B-
J2B2
AI5, AI6
FL1B-
J2B2
AI7, AI8
FL1B-
J2B2
I1..................I8
IDEC Smart-
Relay Basic
Q1...Q4
I9...I12
FL1B-
M08
Q5...Q8
I13...I16
FL1B-
M08
Q9...Q12
I17...I20
FL1B-
M08
Q13...Q16
I21...I24
FL1B-
M08
AI1, AI2
FL1B-
J2B2
AI3, AI4
FL1B-
J2B2
AI5, AI6
FL1B-
J2B2
AI7, AI8
FL1B-
J2B2
