Technical data
IDEC SmartRelay Manual 263
Continuous current I
th
Incandescent lamp load
(25000 switching cycles) at
Fluorescent tubes with ballast
(25000 switching cycles)
Fluorescent tubes,
conventionally compensated
(25000 switching cycles)
Fluorescent tubes, uncompen-
sated (25000 switching cycles)
Short circuit–proof and over-
load–proof
Yes Yes
Short–circuit current limitation Approx. 1 A Approx. 1 A
Derating none; across the en-
tire temperature
range
none; across the en-
tire temperature
range
Short circuit–proof cos 1
Short–circuit proof cos 0.5 to
0.7
Parallel output circuit for power
increase
Not permitted Not permitted
Protection of output relay
(if desired)
Switching rate
Mechanical
Electrical 10 Hz 10 Hz
Ohmic load/lamp load 10 Hz 10 Hz
Inductive load 0.5 Hz 0.5 Hz
FL1C-H12SND FL1B-M08B1S2
