IDEC SmartRelay Series User Manual

Technical data
262
IDEC SmartRelay Manual
Input current at
• Signal 0
• Signal 1
< 1.0 mA (I1...I6)
< 0.05 mA (I7, I8)
> 1.5 mA (I1... I6)
> 0.1 mA (I7, I8)
< 1.0 mA
> 1.5 mA
Delay time at
•0 to 1
•1 to 0
typ. 1.5 ms (I1...I4)
<1.0 ms (I5, I6)
typ. 300 ms (I7,I8)
typ. 1.5 ms (I1...I4)
<1.0 ms (I5, I6)
typ. 300 ms (I7,I8)
typ. 1.5 ms
typ. 1.5 ms
Line length (unshielded) 100 m 100 m
Analog inputs
Number 2 (I7 and I8)
Range 0 ... 10 V DC
input impedance
76 k
Ω
max. input voltage 28.8 V DC
Line length (shielded and twist-
ed)
10 m
Digital outputs
Number 4 4
Output type Transistor,
current–sourcing
Transistor,
current–sourcing
Electrical isolation No No
In groups of
Control of a digital input Yes Yes
Output voltage Supply voltage Supply voltage
Output current max. 0.3 A max. 0.3 A
FL1C-H12SND FL1B-M08B1S2
Courtesy of Steven Engineering, Inc. ● 230 Ryan Way, South San Francisco, CA 94080-6370 ● General Inquiries: (800) 670-4183 ● www.stevenengineering.com
