Technical data
268
IDEC SmartRelay Manual
Delay time at
•0 to 1
•1 to 0
typ. 1.5 ms
<1.0 ms (I5, I6)
typ. 300 ms (I7,I8)
typ. 1.5 ms
<1.0 ms (I5, I6)
typ. 300 ms (I7,I8)
typ. 1.5 ms
typ. 1.5 ms
Line length (unshielded) 100 m 100 m
Analog inputs
Number 2 (I7, I8)
Range 0 ... 10 V DC
input impedance
76 k
Ω
max. Input voltage 28.8 V DC
Line length (shielded and
twisted)
10 m
Digital outputs
Number 4 4
Output type Relay outputs Relay outputs
Electrical isolation Yes Yes
In groups of 1 1
Control of a digital input Yes Yes
Output voltage
Output current
FL1C-H12RCE
FL1C-B12RCE
FL1B-M08B2R2
Courtesy of Steven Engineering, Inc. ● 230 Ryan Way, South San Francisco, CA 94080-6370 ● General Inquiries: (800) 670-4183 ● www.stevenengineering.com
