IDEC SmartRelay functions
IDEC SmartRelay Manual 177
Functional description
The function fetches the analog signal of input Ax.
This value is multiplied by the value of the A (gain) parame-
ter, and parameter B (offset) is then added to the product, i.e.
(Ax • gain) + offset = actual value Ax.
The actual value Ax is output at AQ.
Preset of the Par parameter
The gain and offset parameters are used to adapt the sen-
sors to the relevant application.
View in programming mode (example):
View in parameter assignment mode (example):
B3 +
A =02.50
B =-00300
p=0
Gain
Offset
Decimals in the message text
