IDEC SmartRelay functions
180
IDEC SmartRelay Manual
Functional description
Output Q changes its status, i.e. the output is set or reset,
with each 0 to 1 transition at input Trg and if the inputs S and
R = 0.
The signal at input Trg does not influence the special func-
tion when S or R = 1.
You set the current impulse relay with a signal at input S, i.e.
the output is set hi.
You reset the current impulse relay with a signal at input R,
i.e. the output is set lo.
Status diagram
*: RS or SR
**: Triggering signal is effective, because S and R = 0.
Par Q
n-1
SRTrg Q
n
* 0000 0
*
0
000 ->1 1**
* 0010 0
* 0010 ->1 0
* 0100 1
* 0100 ->1 1
RS 0110 0
RS 0 1 1 0 ->1 0
SR 0110 1
SR 0 1 1 0 ->1 1
* 1000 1
*
1
000 ->1 0**
* 1010 0
* 1010 ->1 0
* 1100 1
* 1100 ->1 1
RS 1110 0
RS 1 1 1 0 ->1 0
SR 1110 1
SR 1 1 1 0 ->1 1
