IDEC SmartRelay functions
IDEC SmartRelay Manual 191
To change ‘Par’ to ‘Switch’ action and the initialization status
after the program start:
4. To select ‘Momentary pushbutton’ or 'Switch’ action:
Press ▲ or ▼
5. To change to the start state: Press or
6. To change the start state: Press ▲ or ▼
7. Confirm your entries with OK
View in parameter assignment mode (example):
Here, you can set or reset the ‘Switch’ parameter (On/Off).
When in RUN, the IDEC SmartRelay shows the following
display:
Let us assume you want to set ‘Switch’ (On).
1. Change to the editing mode: Confirm with OK
(the cursor is now positioned on ‘Off’)
2. To change from ‘Off’ to ‘On’: Press ▲ or ▼
3. Confirm your entries with Press OK
B33 +/
On/Off
Start=On
The status is not retentive
‘Switch’ function
Q is set in the first cycle after the
program start
▲
▲
B33 +/
On/Off
Start=Off
The status is not retentive
‘Switch’ function
Q is reset in the first cycle after
the program start
B33
Switch=Off
The momentary pushbutton/
switch is here switched off
