Configuring IDEC SmartRelay
198
IDEC SmartRelay Manual
Description of the four menu items of the parameter assignment
menu
• Stop
You select this command to stop your circuit program and
thus change to the main menu of programming mode. To do
so:
1. To move the ‘>’ cursor to ‘Stop’: Press ▲ or ▼
2. To confirm ‘Stop’: Press OK
3. To move the ‘>’ cursor to ‘Yes’: Press ▲ or ▼
4. To confirm ‘Yes’: Press OK
IDEC SmartRelay shows the main menu of the programming
mode:
• Set Param
For information on the various parameters, refer to the
Chapters 5.1.1 to 5.1.3.
• Set clock
The ‘Set Clock’ command is only executed if your IDEC
SmartRelay is equipped with a real-time clock (FL1C-
J12RC...). You set the real-time clock of IDEC SmartRelay
by means of the ‘Set Clock’ command. For details, refer to
Chapter 5.2.
• Prg Name
This menu command only allows you to read the name of
your circuit program. It is not possible to modify this name in
parameter assignment mode. (see Chapter 3.6.4.)
>Program..
Card..
Clock..
Start
