IDEC SmartRelay installation and wiring
IDEC SmartRelay Manual 31
FL1C-H12RCE / FL1C-B12RCE / FL1C-H12SND / FL1B-M08B2R2/
FL1C-M08B1S2
FL1C-H12RCE / FL1C-B12RCE / FL1C-H12SND / FL1B-J2B2
FL1B-J2B2
I1~I8
3.3kΩ
2kΩ100nF
M
Internal
Circuit
Digital DC Input
I7, I8
(U1, U2)
M
(M1, M2)
38kΩ
+5V
38kΩ
10nF
Internal
Circuit
Analog Input (0-10V)
Max 125Ω
125Ω 10nF
I1, I2
M1, M2
Internal
Circuit
Analog Input (0-20mA)
Courtesy of Steven Engineering, Inc. ● 230 Ryan Way, South San Francisco, CA 94080-6370 ● General Inquiries: (800) 670-4183 ● www.stevenengineering.com
