Programming IDEC SmartRelay
IDEC SmartRelay Manual 43
IDEC SmartRelay knows the following connectors:
DM: Digital module.
AM: Analog module.
Con-
nectors
IDEC SmartRelay Basic / Pure DM AM
Inputs FL1C-H12RCC
FL1C-B12RCC
FL1C-H12RCA
FL1C-B12RCA
Two groups:
I1... I4 and
I5 ... I8
I9 ... I24 AI1...AI8
FL1C-H12RCE
FL1C-B12RCE
FL1C-H12SND
I1... I6, I7, I8
AI1, AI2
I9 ... I24
AI3...AI8
Outputs Q1...Q4 Q5 ...
Q16
none
lo Logical '0' signals (off)
hi Logical '1' signals (on)
x An existing connection that is not used
