POC-3174B-A330 Medical Panel PC
A.1 Motherboard Specifications
The POC-3174B-A330 comes with an A330 motherboard pre-installed. The technical
specifications of the motherboard are listed in Table 8-1.
Specification A330
CPU 2.0 GHz Intel® Pentium® M processor 760
System Chipset Intel® 915GME + ICH6
BIOS AMI BIOS Label
System Memory 2 x DDR2 SO-DIMM 400/533 MHz (system max. 2 GB)
Ethernet Mini PCIe (Wireless LAN Module)
External I/O 2 x RS-232 COM Ports
2 x USB 2.0
2 x Gigabit LAN
1 x Keyboard
1 x Mouse
1 x VGA
2 x Audio jacks
1 x DVI
Super I/O ITE IT8718
Digital I/O 4 DI / 4 DO from Super IO IT8718
Touch Screen Controller DMC9000
Audio Realtek ALC888 High Definition Audio codec
Display CRT integrated in 915GME -- D-Sub connector
Support panel resolution up to QXGA
Supports 24-bit LVDS output
Power +12 V power adapter
Table 8-1: Motherboard Specifications
