Page 143
POC-3174B-A330 Medical Panel PC
SPECIFICATION 17 inch
Viewing Area (W x H)
(mm)
342.05 x 275.45
Active Area (W x H) 339.0 x 272.40
Total Transmission 78%.
Maximum Voltage 7V.
Connector Type FPC.
Operating
Temperature
-10~50 (
℃
).
Operating Humidity 20%~90 %RH.
Storage Temperature -20~70 (
℃
).
Storage Humidity 20%~90 %RH.
Table 8-3: Touch Panel Specifications
A.4 Power Adapter
The POC-3174B-A330 comes with a MPU-100-105 100 W medical grade switching power
adapter. The specifications of the power adapter are listed in
Table 8-4.
Voltage 90 ~ 264 V AC Full Range
Frequency 47 ~ 63Hz
INPUT
Current Low Line: 1.25 A (Max.)
High Line: 0.5 A (Max.)
Voltage (V) 12 V ~ 13 V DC
Current (A) 8.33 A ~ 7.70 A
OUTPUT
Ripple and Noise
0.5 % (Full Load, Vin=90 V AC)
Over Voltage 112% (Min.), 132% (Max.)
Protection
Over Current 110% (Min.), 150% (Max.)
Watt 100 W
Hold-up time 16 ms minimum
Efficiency 88% (Max.)
GENERAL
MTBF
100,000 hrs at 25°C
