Page 145
POC-3174B-A330 Medical Panel PC
A.6 Wireless LAN Module
The IEEE 802.11a/b/g/n compliant Intel® wireless Wi-Fi Link 4965AGN module is
pre-installed in the system and provides wireless connectivity at up to 300 Mbps. The
wireless module is interfaced to the system chipset through the PCIe Mini slot.
Figure 8-23: Wireless LAN Module
Some of the features of the wireless module are listed below.
Compliant with IEEE 802.11a, 802.11b, 802.11g and 802.11n standards
MIMO, diversity and three-antenna support
Advanced wireless security via 802.11i is supported by WPA2 AES
Business-Class Wireless Suite v2 allows Access Points and clients to change
settings based on network conditions.
40 MHz channels in the 5.0 GHz spectrum
