Page 34
POC-3174B-A330 Medical Panel PC
NOTE:
To load BIOS default, please use the Load Optimal Defaults option of the
Exit menu in the BIOS (refer to Section
on page 94) to load the optimal
default values for each of the parameters on the Setup menus. F9 key can
be used for this operation.
4.9 Mounting the System
WARNING!
When mounting the flat panel PC onto an arm, onto the wall or onto a
stand, it is better to have more than one person to help with the installation
to make sure the panel PC does not fall down and get damaged.
The four methods of mounting the POC-3174B-A330 are listed below.
Wall mounting
Arm mounting
Stand mounting
The four mounting methods are described below.
4.9.1 Wall Mounting
To mount the flat panel PC onto the wall, please follow the steps below.
Step 1: Select the location on the wall for the wall-mounting bracket.
Step 2: Carefully mark the locations of the four brackets screw holes on the wall.
Step 3: Drill four pilot holes at the marked locations on the wall for the bracket retention
screws.
