Page 37
POC-3174B-A330 Medical Panel PC
Figure 4-9: Secure the Panel PC
4.9.2 Arm Mounting
The POC-3174B-A330 is VESA (Video Electronics Standards Association) compliant and
can be mounted on an arm with a 75 mm or 100 mm interface pad. To mount the
POC-3174B-A330 on an arm, please follow the steps below.
Step 1: The arm is a separately purchased item. Please correctly mount the arm onto
the surface it uses as a base. To do this, refer to the installation documentation
that came with the mounting arm.
NOTE:
When purchasing the arm please ensure that it is VESA compliant and that
the arm has a 75 mm or 100 mm interface pad. If the mounting arm is not
VESA compliant it cannot be used to support the POC-3174B-A330.
