Page 43

POC-3174B-A330 Medical Panel PC

Figure 4-15: Serial Device Connector

Step 3: Secure the connector. Secure the serial device connector to the external

interface by tightening the two retention screws on either side of the connector.

Step 0:

4.10.6 USB Device Connection

There are two external USB 2.0 connectors. All connectors are perpendicular to the

POC-3174B-A330. To connect a USB 2.0 or USB 1.1 device, please follow the

instructions below.

Step 1: Locate the USB connectors. The locations of the USB connectors are shown

in Chapter 2.

Step 2: Align the connectors. Align the USB device connector with one of the

connectors on the bottom panel. See

Figure 4-16.
