Page 30

POC-3174B-A330 Medical Panel PC

internal chassis (see Figure 2-15). To prevent these antennas from

damage, be very careful when lifting the back cover off the

POC-3174B-A330.

To remove the back cover, remove the nine retention screws indicated below (Figure 4-1)

and carefully lift the back cover off the POC-3174B-A330.

Figure 4-1: Back Cover Retention Screws

4.5 Connect the Battery

The POC-3174B-A330 panel PC is preinstalled with a Li-on battery. To start using the

battery for backup power, the battery connector must be connected. To connect the

battery, follow the steps below.

Step 1: Remove the plastic back cover. See Section

4.4.

Step 2: Locate the battery cable. Connect the battery cable to the battery connector

(

Figure 4-2). Step 0:
