Page 144
POC-3174B-A330 Medical Panel PC
Temperature 0~70
℃
(Operating)
-40~85
℃
(Storage)
Humidity 5~95%
Dimension 89.5 mm (W) x 45.5 mm (H) x 188.9 mm (D)
Table 8-4: Power Supply Specifications
A.5 Battery Specifications
The POC-3174B-A330 series come with a Lithium-ion battery. Some of the Lithium-ion
battery specifications are listed in
Table 8-5.
Model Name BAT-LI-4S2P3800
Battery Type Li-ion 4S2P 14.8V
Battery Capacity 14.8 V, 3800 mAH
Maximum Charge Voltage 16.8 V
The End of Discharging Voltage 11.2 V
Suggestive Charging Current
(Max.)
2 A
System Continuous Discharging
Current (Max)
7.6 A
The End of Charge Condition 200 mA/1Min
Discharge Protection UVP/OCP
Charge Protection OVP/OCP
Ambient Temp. 0
℃
~40
℃
Storage Tem. -20
℃
~60
℃
Self-discharge Rate 340 mA~440 uA
Dimensions 164.99 mm (D) X 75.99 mm (W) X 25.4 mm (H)
Weight 446 g
Life cycles 300 times charge/discharge
Safety class CE, UL, TUV
Table 8-5: BAT-LI-4S2P3800 Specifications
