IEI Technology POC-3174B-A330 User Manual

Page 22
POC-3174B-A330 Medical Panel PC
2.8.5 Power On/Off
On UPS Mode Battery Mode
Battery Only NOT able to turn on by the
power button.
Battery Only NOT able to turn on by the
power button.
AT Mode
Battery +
Adapter
Turn on automatically when
the power is connected.
Battery +
Adapter
Turn on automatically when
the power is connected.
Battery Only NOT able to turn on by the
power button.
Battery Only Able to turn on by the power
button
ATX Mode
Battery +
Adapter
A
ble to turn on by the power
button
Battery +
Adapter
A
ble to turn on by the power
button
Table 2-1: Power Modes (Turning on the System)
Off UPS Mode Battery Mode
Battery Only
A
ble to turn off by the power
button and the power will be
disconnected.
Battery Only
A
ble to turn off by the power
button and the power will be
disconnected.
AT Mode
Battery +
Adapter
A
ble to turn off by the power
button and the power will be
disconnected.
Battery +
Adapter
A
ble to turn off by the power
button and the power will be
disconnected.
Battery Only Able to turn off the system
in the OS.
Battery Only
A
ble to turn off the system in
the OS.
ATX Mode
Battery +
Adapter
Able to turn off the system
in the OS.
Battery +
Adapter
A
ble to turn off the system in
the OS.
Table 2-2: Power Modes (Turning off the System)
