IEI Technology POC-3174B-A330 User Manual

Page 5
POC-3174B-A330 Medical Panel PC
Volume Adjustment
Volume “+”
Volume “-”
Backlight Brightness
Adjustment
Brightness”+”
Brightness”-”
Table 1-1: LCD Front Controls
1.2.2 Rear Panel
The rear panel provides access to fan ventilation vents and retention screw holes that
support a 100 mm x 100 mm or a 75 mm x 75 mm VESA standard wall mount or desktop
stand. See
Figure 1-3.
Figure 1-3: Rear View
1.2.3 Bottom Panel
The bottom panel of the POC-3174B-A330 has the following I/O interfaces (Figure 1-4):
 1 x AT/ATX mode switch
