IEI Technology POC-3174B-A330 User Manual

Page 142
POC-3174B-A330 Medical Panel PC
A.2 Flat Panel Screen Specifications
The POC-3174B-A330 comes with a TFT LCD monitor at the front of the flat panel PC.
The specifications for the LCD monitor are shown in
Table 8-2 below.
SPECIFICATION 17 inch
Active Area (H x V) (mm) 337.9 x 270.3
Physical Size
(W x H x D) (mm)
358.5 x 296.5 x 15.0
Resolution (Pixel) 1280 x 1024
Brightness 300 (cd/m
2
)
Pixel Pitch (mm) 0.264
LCD Color Native 16.7M Colors (RGB 6-bit driver)
Electrical Interface Dual-channel LVDS
Contrast Ratio 800:1
Optical Response Time 5 msec
Viewing Angle (H / V)
(degrees)
160 / 160
Backlight 4 CCFL
Nominal Input Voltage 5.0 V
Power Consumption 25.8 W
Table 8-2: TFT LCD Monitor Specifications
A.3 Touch Screen Specifications
The POC-3174B-A330 comes with an analog resistive type touch panel. Table 8-3 lists
the touch panel specifications.
SPECIFICATION 17 inch
Control Board Chipset on the A330 motherboard (DMC9000)
Sensor Model PANJIT 75200-1171505A-RS, 5-wire Analog Resistive Type Touch Panel.
Glass Dimensional
Outline (W x L x T)
(mm)
365.0 x 295.08 x 2.9
