IEI Technology POC-3174B-A330 User Manual

Page 81
POC-3174B-A330 Medical Panel PC
 115200 8,n,1 DEFAULT
 57600 8,n,1
 38400 8,n,1
 19200 8,n,1
 09600 8,n,1
NOTE:
Identical baud rate setting musts be set on the host (a management
computer running a terminal software) and the slave
 Redirection After BIOS POST [Always]
Use the Redirection After BIOS POST option to specify when console redirection should
occur.

Disabled
The console is not redirected after POST

Boot Loader
Redirection is active during POST and during Boot
Loader

Always DEFAULT
Redirection is always active (Some OSes may not
work if set to Always)
 Terminal Type [ANSI]
Use the Terminal Type BIOS option to specify the remote terminal type.

ANSI DEFAULT
The target terminal type is ANSI

VT100
The target terminal type is VT100

VT-UTF8
The target terminal type is VT-UTF8

IEI Technology POC-3174B-A330 Specifications

General

Brand	IEI Technology
Model	POC-3174B-A330
Category	Desktop
Language	English
