IEI Technology POC-3174B-A330 User Manual

Page 76
POC-3174B-A330 Medical Panel PC
which the cooling fan should automatically turn off. To select a value, select the Temp.
Limit of OFF option and enter a decimal number between 000 and 127. The temperature
range is specified below.
 Minimum Value: 0°C
 Maximum Value: 127°C
 Temp. Limit of Start
WARNING:
Setting this value too high may cause the fan to start only when the
CPU is at a high temperature and therefore cause the system to be
damaged.
The Temp. Limit of Start option can only be set if the FAN Mode Setting option is set to
Automatic Mode. Use the Temp. Limit of Start option to select the CPU temperature at
which the cooling fan should automatically turn on. When the fan starts, it rotates using the
starting pulse width modulation (PWM) specified in the Fan Start PWM option below. To
select a value, select the Temp. Limit of Start option and enter a decimal number
between 000 and 127. The temperature range is specified below.
 Minimum Value: 0°C
 Maximum Value: 127°C
 Fan Start PWM
The Fan Start PWM option can only be set if the FAN Mode Setting option is set to
Automatic Mode. Use the Fan Start PWM option to select the PWM mode the fan starts
to rotate with after the temperature specified in the Temperature 3 Limit of Start is
exceeded. The Super I/O chipset supports 128 PWM modes. To select a value, select the
Fan Start PWM option and enter a decimal number between 000 and 127. The
temperature range is specified below.
