2.3.1 BAR LOADING CYCLE - FACING PROCEDURE
The following procedure describes the feeding of a new bar until the facing position is reached:
Press the
buttons with the key for 6 seconds.
The bar feeder starts the bar loading cycle, which stops when the new bar is positioned. The
loading cycle of the new bar takes into account parameter 3 (facing mode) and parameter 2
(facing position).
If the operator releases the
buttons or the key, the cycle goes on until it is
completed.
INFORMATION:
Without the open collet signal from lathe, the bar feeder carries out the above
mentioned procedure, but the bar stops before entering the lathe collet (waiting
for the open collet signal). With the open collet signal from lathe, the bar is
loaded and positioned past the lathe collet according to parameters 2 and 3.
WARNING - CAUTION:
Check that the bar to be loaded in the magazine is present.
