2 - INFORMATION FOR USE KID 80 SIV
2 - Pag. 42 / 66
no. 32 K1 immediate exit
0 - (with open collet K1 is not activated).
When detected, the bar end signal K1 is sent
to the lathe at the "COLLET CLOSING".
1 - (with open collet K1 is activated). When
detected, the bar end signal K1 is
immediately sent to the lathe during the
"FEEDING" signal.
no. 33 K2 inversion
0 - (K2 is on 1 at limit stop). During the
feeding signal, the K2 relay remains off
during the bar feeding; it is activated when
the bar arrives at the bar limit stop (encoder
stop).
1 - (K2 is on 0 at limit stop). The K2 relay is
active during the bar feeding and off when
the bar reaches the bar limit stop (encoder
stop).
32
no. 32 K1 immediate exit
xxxxxxxxxx
DEFAULT VALUE
PROGRAMMABLE
VALUE
KID KID
0 0
33
no. 33 K2 inversion
xxxxxxxxxx
DEFAULT VALUE
PROGRAMMABLE
VALUE
KID KID
0 0
