2 - INFORMATION FOR USE KID 80 SIV
2 - Pag. 32 / 66
no. 19 Spindle pulses - off-time
Defines the duration of the OFF pulse given
to the lathe to slow down and stop the
spindle, prior to the following rotation pulse
(see phase description in parameter 18).
no. 20 Cycle start delay
When the bar is in the facing position (see
parameter 2), the "cycle start" signal of the
lathe can be delayed for a preset value
(K15).
Application example: it is necessary to have
the “cycle start” signal delay when the
spindle needs a certain time to reach the
operating rotation speed.
19
no. 19 Spindle
pulses -
off-time
xxxx (sec)
DEFAULT VALUE
PROGRAMMABLE
VALUE
KID KID
1 0/1/2/3
20
no. 20 Cycle start
delay
xxxx (sec)
DEFAULT VALUE
PROGRAMMABLE
VALUE
KID KID
1 0/1/2/3
