IEMCA KID 80 - Open Collet Thrust Delay; Closed Collet Thrust Delay

2 - INFORMATION FOR USE KID 80 SIV
EN
2 - Pag. 25 / 66
no. 9 Open collet thrust delay
At the "FEEDING" signal from the lathe,
the bar pusher delays the feeding in
accordance to the set time.
Application example: it should be used
when the mechanical movement of the
collet opening is slow (double-cone
collet).
no. 10 Closed collet thrust delay
At the "closed collet" signal from the
lathe, the bar pusher continues pushing in
accordance to the set time.
Application example: it should be used
when the mechanical movement of the
collet closing is slow (double-cone collet).
9
no. 9 Open collet
thrust delay
xxxx (sec)
DEFAULT VALUE
PROGRAMMABLE
VALUE
KID KID
0 /
10
no. 10 Closed collet
thrust delay
xxxx (sec)
DEFAULT VALUE
PROGRAMMABLE
VALUE
KID KID
0 /
