IEMCA KID 80 - Pulse Stroke; Spindle Pulses - On-Time

2 - INFORMATION FOR USE KID 80 SIV
EN
2 - Pag. 31 / 66
no. 15 Pulse stroke
Defines the length of the forward and
backward stroke of the pulses (see
parameter 14).
no. 18 Spindle pulses - on-time
Defines the duration of the ON pulse that
the lathe receives to make the spindle
turn.
This is necessary to simplify the entry of
the shaped bars into the collet.
Description of the phase order:
- the bar moves into the slowdown
section (see parameter 11);
- the bar meets the obstacle (the collet)
and the lathe receives the pulses to
start turning the spindle for the set
time;
- the spindle slows down and then stops
(for the time defined in parameter 19);
- the bar receives the feeding pulse;
- if the bar is fed into the collet, the
cycle goes on;
- if the bar does not enter into the
collet, the previous phases will be repeated.
15
no. 15 Pulse stroke
XXXX (mm)
(inches)
DEFAULT VALUE
PROGRAMMABLE
VALUE
KID KID
0.15 /
18
no. 18 Spindle
pulses -
on-time
xxxx (sec)
DEFAULT VALUE
PROGRAMMABLE
VALUE
KID KID
1 0/1/2/3
