Function Application
‑549‑
Value
Function
Detailed Description
53
Thickness
accumulation
When the roll diameter is calculated based on
accumulative thickness, the terminal is used to record
the number of revolutions.
54
Roll diameter reset When the terminal is active, the initial roll diameter is
reset. The initial roll diameter is reset upon reel
replacement when the tension mode is used.
55
Initial roll diameter 1 In the tension mode, you can combine terminals to
select the initial roll diameter B0‑11/12/13.
When terminals of both initial roll diameter 1 and initial
roll diameter 2 are inactive, the minimum roll diameter
B0‑09 is used as the initial roll diameter.
When only the terminal of initial roll diameter 1 is
active, B0‑11 is used as the initial roll diameter.
When only the terminal of initial roll diameter 2 is
active, B0‑12 is used as the initial roll diameter.
When terminals of both initial roll diameter 1 and initial
roll diameter 2 are active, B0‑13 is used as the initial
roll diameter.
56
Initial roll diameter 2
57
Pre‑drive When the terminal is active, the AC drive switches to
the pre‑drive speed control mode. This function is used
to synchronize the linear speed for the axis that
requires automatic reel replacement when the tension
mode is used. When the terminal is inactive after reel
replacement, the tension control can function properly.
58
Winding/unwinding
switchover
This function is used to switch between winding and
unwinding when the tension mode is used.
59
Roll diameter
calculation disabled
When the terminal is activated, the roll diameter
calculation is disabled. This function is used to disable
roll diameter calculation to prevent automatic reel
replacement and pre‑drive from affecting roll diameter
calculation when the tension mode is used.
60
Exiting tension mode This function is used to exit the tension control mode.
61
Terminal tension rise When the terminal is activated, the tension torque is
increased by certain ratio. After the DI terminal is
deactivated, the boost part will be canceled gradually
based on time.
